Sony PS-X60 (1978-1980)

Name: Sony ps-x60
Brand: Sony

Direct-drive full-auto turntable with crystal-locked speed control and PUA-7 tonearm, produced by Sony from 1978 to 1980.

Overview

The Sony PS-X60 is a full-auto stereo turntable system manufactured by Sony Corporation in Tokyo between September 1978 and 1980. It features a direct drive system with Xtal quartz-lock speed control, achieving correct playback speed in just over a second. The turntable uses a 32 cm aluminum die-cast platter with a magnetic strip on the inner rim, read by a tape head as part of the speed regulation system. It was designed for high precision, with wow and flutter measured at 0.025% wrms and velocity drift of 0.0003% per hour or less.

Specifications

Production Years	September 1978 – 1980
Drive Type	Direct Drive
Speed Control	Xtal Quartz-Lock System
Wow and Flutter	0.025% wrms
Signal-to-Noise Ratio	75dB (DIN-B)
Turntable Diameter	32 cm Aluminum Die Cast
Turntable Weight	2.2 kg (including rubber sheet)
Moment of Inertia	340 kg/cm²
Tonearm Model	PUA-7
Tonearm Effective Length	235 mm
Tonearm Total Length	330 mm
Arm Height Adjustment	±3 mm
Needle Pressure Range	0–2.5g (0.1g intervals)
Anti-Skating Range	0–2.5g
Cartridge Type	MM Type (XL-25A)
Cartridge Output Voltage	4 mV (1 kHz, 5 cm/s, 45°)
Cartridge Frequency Characteristic	10 Hz – 30 kHz
Cartridge Needle	0.3 x 0.8 mil Diamond Oval
Cartridge Dead Weight	5.2 g
Shell Dead Weight	11.0 g (SH-155)
Usable Cartridge Weight	11.0–19.5g (27.5g with auxiliary weight)
Overhang	14 mm
Tonearm Balance	Static
Cable Capacitance	50 pF/m
External Dimensions	480 mm (W) × 165 mm (H) × 420 mm (D)
Weight	Approx. 12 kg
Original Price	¥62,800 (circa 1979)

Design

The PS-X60 uses a slotless linear BSL motor without brushes or slots, contributing to stable rotation. Speed is monitored via a Magne-disk system: a magnetic strip on the turntable’s inner circumference contains 512 wave detection signals read by a multi-gap head. The servo circuit employs a crystal oscillation phase control for precise speed locking. The PUA-7 tonearm features a rigid J-shaped aluminum alloy arm pipe offering approximately 8 times the rigidity of conventional designs. Arm height is adjusted via a locking lever on the right side, and anti-skating is adjustable during playback using an engraved ring. The tonearm connects via a wedge-lock mechanism in the neck cylinder for secure contact. The plinth is made of SBMC material and includes gel-filled rubber insulators for vibration damping. A luminous sensor enables electronic record-end detection, and an arm limiter mechanism is included. Control functions are located outside the dust cover, with a rotary switch for auto/manual selection and a rocker switch for arm lift/lower.

Context

The PS-X60 is part of Sony’s PS-X series, positioned as a later addition following the original PS-X70 and PS-X50 models. It shares design elements with the PS-X70 and PS-X50, and was succeeded by the PS-X65. Other models in the series include the PS-X40 and PS-X30.

Market

Reviewer impressions highlight the PS-X60’s "sublime" imaging, perfect speed stability, and "utter musicality," describing it as a superb, plug-and-play turntable suitable for most listeners. One unit was noted to have been used as a painter’s drop sheet and glue-mixing platform, indicating potential vulnerability to physical abuse. When properly serviced, it is expected to have exceptional longevity. Estimated resale value is unlikely to exceed $400.
