Hasselblad 120mm f/4 Makro-Planar CFi T* Lens (Undated)

A manual focus macro lens for the Hasselblad 500 Series V System, optimized for close-up work at 1:4.5 reproduction ratio

Overview

This is a 120mm f/4 macro lens made by Hasselblad for use with their 500 Series V System cameras. It's part of the Makro-Planar line, engineered for high-resolution close focusing. At its closest, it achieves a 1:4.5 reproduction ratio, and with the optional Hasselblad Extension Tube 32, that increases to 1:2. The lens was used with the Hasselblad H3D-22 digital system and has been in use since at least the early 1990s. It succeeds the 120mm S-Planar T* f/5.6 lens and is described as exceedingly well made.

Specifications

Focal length	120mm
Maximum aperture	f/4
Closest focusing distance	0.8 m
Reproduction ratio	1:4.5
Maximum reproduction ratio with extension	1:2 (using Hasselblad Extension Tube 32)
Used with camera	Hasselblad H3D-22
Compatibility	For Hasselblad 500 Series V System
Coating	T*
Lens type	Makro-Planar CFi

Design

The Makro-Planar CFi version is described as exceedingly well made. It follows the design lineage of the earlier 120mm S-Planar T* f/5.6, which it replaces. The CB variant of this lens is engineered in black, though finish details for the CFi are not specified.

Context

The 120mm Makro-Planar succeeded the 120mm S-Planar T* f/5.6 lens in Hasselblad’s V-system lineup. It was used for macro and tight-focus applications, including portrait-like work at close range. Both the S-Planar and Makro-Planar share the same minimum focus distance, but the Makro-Planar delivers superior macro performance.

Market

In 2024, a fair market price for the 120mm CF variant was estimated between 650 and 750 Euros on eBay, with dealers asking 800 to 1000 Euros. A 2005 listing suggested a used price around $110, indicating significant appreciation. Example CFi units have been noted with excellent glass—no haze, fungus, or cleaning marks.
