Japanese-made 3-way bookshelf speaker with hermetically sealed cabinet and multi-amplifier input support
Overview
The Pioneer CS-700 is a 3-way bookshelf speaker system made in Japan by Pioneer Corporation. Note: it is unclear if 'Pioneer CS-700' and 'Pioneer CS-700G' are the same model, and the facts here are explicitly for the 'CS-700G' variant. It has a 30 cm cone woofer, a 12 cm cone midrange, and a multi-cellar horn-type tweeter for the high frequencies. The enclosure is thick particle board and hermetically sealed, so it is airtight. The finish is walnut oil, and the grille is brown fabric.
Specifications
| Type | 3-Way, 3-Speaker, Airtight Type, Bookshelf Type |
| Woofer | 30 cm cone type |
| Midrange | 12 cm cone type |
| Tweeter | Horn Type (multi-cellar horn) |
| Impedance | 8 Ω |
| Frequency Response | 35 Hz to 20 kHz |
| Sound Pressure Level | 95dB/W |
| Max Input | 60W |
| Crossover Frequencies | Normal: 500 Hz, 5 kHz; Multi-amp 2-way: 500 Hz to 1 kHz; Multi-amp 3-way: 500 Hz to 1 kHz, 4 kHz to 6 kHz |
| Dimensions | Width 380 × Height 660 × Depth 320 mm |
| Weight | 16.9 kg |
Design
The CS-700 uses FB cone diaphragms for both the woofer and the midrange, plus the multi-cellar horn tweeter. The cabinet is thick particle board, hermetically sealed. A 3-step switching type level control is built in. Multi-amplifier operation goes through dedicated rear terminals, and a switch turns them on. The outside is walnut oil with a brown fabric grille.
Market
The original price was ¥33,000 per unit around 1973. As of 2026, a used pair was listed for RON 3,500 on Audioweb. A single unit was auctioned on Yahoo Auctions starting at ¥1,500, with defects noted. A pre-owned unit was listed on eBay for $450.00. Current listings describe the model as "Rare Vintage".
Market Value
┌──────────────────────────────────────────────────────────────────────────┐ │ PIONEER CS-700 Aug 2026 │ ├──────────────────────────────────────────────────────────────────────────┤ │ High $60 Latest $25 │ │ Median $25 Trend — │ │ Low $24 Volume ~1/mo │ ├──────────────────────────────────────────────────────────────────────────┤ │ $100 ┤ │ │ │ │ │ │ │ │ $57 ┤ . │ │ │ │ │ │ │ │ │. . .│ │ $0 ┤ │ │ ├─────────────────────────────────────────────────────────────────│ │ vol │█ █ █ █│ │ └─────────────────────────────────────────────────────────────────│ │ 2026-01 2026-04 2026-06│ └──────────────────────────────────────────────────────────────────────────┘
eBay completed sales. Excludes accessories, parts, and non-working units. Hover points for details.
