McIntosh MC150
Fifty-nine pounds of solid-state iron that will deliver 150 watts into a two-ohm load without breaking a sweat.
Overview
The MC150 is a stereo power amplifier from McIntosh Laboratory, Inc. of Binghamton, New York. The surviving factory documentation describes it plainly: 150 watts minimum sine wave continuous average power output per channel, both channels operating, into 2, 4, or 8 ohms. Most amplifiers quote their power into 8 ohms and quietly hope you never ask about 4. The MC150 is rated for the same 150 watts on all three load impedances - 17.3 volts RMS across 2 ohms, 24.5 volts across 4, 34.6 volts across 8.
The distortion figures are where the engineering gets serious. Total harmonic distortion is specified at 0.005% maximum at any power level from 250 milliwatts up to 150 watts per channel, 20Hz to 20,000Hz, both channels running. Intermodulation distortion carries the same 0.005% ceiling, measured with instantaneous peaks up to 300 watts per channel across any combination of frequencies in the same band. These are not numbers pulled at 1kHz and 1 watt. They hold across the entire audio band and the entire useful power range.
For mono use the amplifier can be strapped two ways. Bridged, it produces 300 watts minimum sine wave continuous average power into 4, 8, or 16 ohms - 34.6 volts RMS across 4 ohms, 49.0 volts across 8, 69.3 volts across 16. In parallel-mono configuration it delivers the same 300 watts into 1, 2, or 4 ohms, which is the mode for a punishing low-impedance load.
It is a full-width component. The front panel measures 17-1/2 inches (44.5cm) wide by 5-3/8 inches (13.7cm) high, and the chassis extends 19-3/4 inches (50.2cm) behind the mounting panel once you account for connector clearance. Plan on 1-1/8 inches (2.9cm) of knob clearance in front. Net weight is 59 pounds (26.8kg), and it ships at 76 pounds (34.5kg) in the carton, so check the shipping weight before you buy one from across the country. The serial number range matters for parts. Control knobs changed at serial LM1421, with part 090212 used from LM1001 through LM1420 and part 090215 from LM1421 onward. If you are chasing a missing knob, that break point is the difference between the right part and a knob that almost fits.
The documentation carries the usual McIntosh caveat. The company reserves the right to improve design without notice, and because of ongoing changes to circuitry and components it cannot warrant the accuracy of the schematic material, which is intended for information only. That is boilerplate, but service technicians chasing a late-production unit against an early schematic should expect to find differences.
Design and Service Notes
McIntosh's own schematic notes lay out the conventions a technician needs. The heavy lines on the drawings denote the primary signal path. Unless otherwise noted, all indicated voltages are measured with AC input at 120 volts, 50/60Hz, and are accurate to ±10% with respect to ground. They require a high-impedance (10 megohm) voltmeter to read correctly, so a cheap DMM will lie to you. Resistor values are in ohms, capacitor values in microfarads, inductor values in microhenries. Voltages drawn inside a box are signal voltages, measured with a 1.4V, 1kHz signal fed to both channels with the front panel set to POWER ON and METER WATTS.
A good part of this amplifier is mechanical as well as electrical, and the parts list shows it. Beyond the front panel assembly itself (part 048696), there are end caps, a bottom panel extrusion, a top panel extrusion, and a knob felt washer. On the power side, the interconnection diagram lists the bridge rectifier as a GBPC3504, a 5-ohm thermistor, and a pair of thermal switches alongside the power switch. Fusing differs by market. The export version uses a 3.2A, 240V slow-blow fuse where the domestic build calls for a 6.25A, 240V slow-blow.
The manual warns that components marked with the critical-characteristics symbol must be replaced only with parts recommended by the manufacturer. In a direct-coupled solid-state amplifier, a random transistor or capacitor in a critical spot is a good way to turn a working amplifier into a project.
Market Value
┌──────────────────────────────────────────────────────────────────────────┐ │ MCINTOSH MC150 Oct 2026 │ ├──────────────────────────────────────────────────────────────────────────┤ │ High $5,767 Latest $5,767 │ │ Median $2,199 Trend — │ │ Low $2,099 Volume — │ ├──────────────────────────────────────────────────────────────────────────┤ │ $6,000 ┤ │ │ │ .│ │ │ │ │ $4,286 ┤ │ │ │ │ │ │ │ │ │ │ │ $2,000 ┤. . │ │ ├─────────────────────────────────────────────────────────────────│ │ vol │█ █ █│ │ └─────────────────────────────────────────────────────────────────│ │ 2025-10 2026-01 2026-04│ └──────────────────────────────────────────────────────────────────────────┘
eBay completed sales. Excludes accessories, parts, and non-working units. Hover points for details.
