JBL 2391 / 2392 Horn & Lens Assemblies
Born in the golden era of professional audio, the JBL 2391 and 2392 slant-plate horn assemblies deliver precision-engineered dispersion for high-frequency control in studio and sound reinforcement systems. These aren’t just horns—they’re acoustic tools, built to shape sound with surgical accuracy. The 2391 pairs the 2307 horn with the 2308 lens for 1" drivers, while the 2392 mates the shorter 2311 horn with the same 2308 lens, optimized for 2" drivers. Both yield a tight 80° horizontal by 45° vertical coverage pattern, making them favorites in vintage JBL multi-way systems where clarity and directionality matter.
Specifications
| Type | Slant-Plate Acoustic Lens with Exponential Horn |
|---|---|
| 2391 Components | 2307 Horn + 2308 Lens (for 1" drivers) |
| 2392 Components | 2311 Horn + 2308 Lens (for 2" drivers) |
| Coverage Pattern | 80° horizontal x 45° vertical (above 1200 Hz) |
| Frequency Range | Above 800-1200 Hz (800 Hz for short throw, 1200 Hz recommended) |
| Sensitivity | 108 dB (1W/1m, 4V into 16Ω, warbled crossover to 2.5 kHz) |
| Throat Diameter (2391) | 25 mm (1 inch) - accepts 1" drivers only |
| Throat Diameter (2392) | 50 mm (2 inch) - accepts 2" drivers |
| Nominal Q | 2.5 (2 kHz octave band) |
| Maximum Throw | 9 m (30 ft) |
| Horn Dimensions (2391) | 156 x 197 mm (6⅛ x 7¾ in) |
| Horn Dimensions (2392) | 156 x 117 mm (6⅛ x 4⅝ in) |
| Lens Dimensions | 156 x 254 x 56 mm (6⅛ x 10 x 2¼ in) |
| Weight | 1.8 kg (4 lb) |
Design Overview
JBL’s slant-plate lens technology was a game-changer for consistent high-frequency dispersion—and the 2391 and 2392 put it on full display. At their core is the 2308 slant-plate lens, a precision-machined waveguide that angles sound into a stable 80° x 45° pattern. Paired with the right horn, it tames the wild highs and delivers uniform coverage across the listening plane.
The 2391 uses the deeper 2307 horn, tuned for 1" compression drivers, giving it a slightly extended reach and tighter focus. The 2392, with its shorter 2311 horn, is built for 2" drivers—offering robust output with the same controlled dispersion. Both maintain their pattern integrity above 1200 Hz, making them ideal for systems where high-frequency clarity can’t be left to chance.
Installation Requirements
These aren’t plug-and-play add-ons—they demand proper mounting to perform as designed. Without a cabinet, each assembly needs a solid foundation: a minimum 300 mm x 300 mm (12" x 12") baffle to prevent rear wave interference. The sides of the lens plate must remain unobstructed; any blockage disrupts the carefully engineered wavefront and smears the high end. And above all, the seal between driver and horn throat must be airtight—leaks here kill efficiency and muddy the response.
Crossover Recommendations
While 1200 Hz is the sweet spot for most setups, the 2391 and 2392 offer flexibility. Running them at 1200 Hz ensures optimal pattern control and driver protection. But in short-throw applications—especially within integrated systems—dropping to 800 Hz is viable, provided the driver can handle the lower excursion. It’s a balance: push the crossover down, and you gain output at the cost of dispersion precision.
Compatible Drivers
2391 (1" throat):
- JBL LE85 - Classic 1" compression driver
- JBL 2425 - Titanium diaphragm 1" driver
- Other professional 1" throat compression drivers
2392 (2" throat):
- JBL 2420 - 2" Alnico compression driver
- JBL 2421 - Evolution with improved phase plug
- JBL 2441 - 4" diaphragm professional driver
- Other 2" throat compression drivers
Applications
These assemblies were built for purpose. In professional studio monitors, they deliver crisp, focused highs without coloration. In two- or three-way systems, they integrate seamlessly, offering predictable coverage and strong output. Whether reinforcing sound in a theater, a broadcast booth, or a vintage hi-fi stack, the 2391 and 2392 excel where throw and directionality matter—up to 9 meters with confidence.
Comparison to 2307/2308
The 2307/2308 combination is essentially the disassembled version of the 2391. While the 2391 packages the 2307 horn and 2308 lens as a ready-to-mount unit, the 2307/2308 documentation focuses on DIY integration—especially for builds like the legendary 4355 studio monitor. Same performance, different path to installation.
