Mark Levinson No.26 (1987–1993)
A hand-built analog preamplifier. The No.26 was built with no compromises.
Overview
The Mark Levinson No.26 was designed to redefine the high-end audio market, not just compete in it. From 1987 to 1993, this 70-pound unit of machined aluminum and military-grade circuitry was the flagship of analog preamplification. It was so overbuilt that most of its contemporaries look like toys next to it. It was made in the United States during the golden age of American high-end audio, and it took engineering ego, budgetary freedom and audiophile obsession to get it built. Recording engineers, mastering studios and a select group of private collectors treated the No.26 as a reference standard.
The No.26 is about philosophy as much as sound. While other manufacturers were still wrestling with op-amps and shared power supplies, Mark Levinson went full dual-mono, with entirely separate left and right signal paths from input to output, including independent grounding and shielding. The volume control is a relay-switched stepped attenuator using precision metal-film resistors, which eliminates the channel drift and wear that come with potentiometers. It runs from an external, regulated PSU-1 power supply. The result is transparency, silence and dynamic authority.
Specifications
| Configuration | Dual-mono design |
| Gain | 12 dB |
| Frequency Response | 10 Hz to 100 kHz, ±0.5 dB |
| Total Harmonic Distortion | < 0.01% at 1 kHz, 2 V output |
| Signal to Noise Ratio | 120 dB (re: 2 V output, 20 Hz to 20 kHz) |
| Input Impedance | 100 kΩ |
| Output Impedance | 100 Ω |
| Maximum Output Voltage | 20 V RMS |
| Crosstalk | -120 dB at 1 kHz, -90 dB at 20 kHz |
| Input Channels | 7 (4 line-level, 1 tape, 2 balanced) |
| Output Channels | 2 (main, tape) |
| Power Consumption | 100 watts |
| Dimensions | 19 in × 7.5 in × 18 in (48.3 cm × 19.1 cm × 45.7 cm) |
| Weight | 70 lbs (31.8 kg) |
| Power Supply | External regulated power supply unit (PSU-1) |
Key Features
- Dual-Mono Architecture: The No.26 didn’t just separate left and right channels—it quarantined them. Each channel had its own dedicated circuit board, grounding scheme, and signal path, with no shared components or traces. This wasn’t just good engineering; it was obsessive. The result? Crosstalk measured at -120 dB at 1 kHz, a figure so low it bordered on the theoretical. In practice, this meant instruments occupied precise, holographic positions in the soundstage, with zero bleed between channels.
- Relay-Switched Stepped Attenuator: Forget volume knobs—this preamp used a bank of gold-plated relays to switch between precision 0.1%-tolerance metal-film resistors. No pots, no wear, no channel imbalance over time (in theory). Each volume step was repeatable to within a fraction of a decibel, making A/B comparisons between systems or recordings shockingly accurate. It also eliminated the “fader fatigue” common in even high-end potentiometers, which degrade over time and introduce noise. The only downside? The soft, mechanical click with each volume change—like a luxury watch being wound.
- External PSU-1 Power Supply: The No.26 didn’t just use an external power supply—it demanded one. The PSU-1 was a massive, regulated linear supply that delivered ultra-clean, ripple-free power. By removing the transformer and rectifiers from the main chassis, Mark Levinson eliminated magnetic and electrical interference at the source. This wasn’t just about reducing noise; it was about creating a silent black backdrop against which even the faintest musical details could emerge. The PSU-1 was so overbuilt, it was later reused in the Mark Levinson No.28.
- Discrete Class-A Circuitry: No integrated circuits were allowed near the signal path. Every gain stage used discrete bipolar transistors operating in pure Class A, ensuring linearity and low distortion. The No.26’s THD of less than 0.01% at 1 kHz wasn’t just impressive on paper—it was inaudible in practice. Combined with a 120 dB signal-to-noise ratio, it meant you weren’t hearing the preamp; you were hearing what the preamp was letting through.
Historical Context
The No.26 arrived in 1987. The industry was moving from tubes to solid-state, but most "high-end" preamps still used shared power supplies, op-amps and stereo potentiometers. The Mark Levinson No.23, its predecessor, was already legendary, but it was a stereo design with a single chassis. The No.26 was a bigger jump than an evolution. By going dual-mono and moving the power supply outside the chassis, Mark Levinson built a new category of component, not just a better No.23.
Competitors like the Audio Research Reference 3 offered tube warmth and midrange liquidity, but couldn't match the No.26's neutrality, bandwidth or dynamic control. The No.26 didn't color the sound. It revealed it, for better or worse. If your system had flaws, the No.26 would expose them like an X-ray. That made it a favorite in professional mastering studios, including Sterling Sound and Masterdisk, where engineers needed absolute transparency. Within five years, dual-mono designs with external power supplies became the benchmark for ultra-high-end preamps from companies like Krell, Conrad-Johnson, and even high-end divisions of Japanese giants.
By 1993, the No.26 was succeeded by the Mark Levinson No.28, which added remote volume control and further refinements. The No.26 came before digital controls, microprocessors and remote apps. It was the last of the hand-wired, no-compromise preamps built before the digital age fully arrived.
Collectibility & Value
Today the Mark Levinson No.26 is rare. Production was limited, and units often sat in climate-controlled studios or got passed down like heirlooms, so a clean example is hard to find. In 2025, a fully functional No.26 in good condition goes for between $8,000 and $15,000 USD. The upgraded Mark Levinson No.26S has improved regulation, upgraded capacitors and enhanced shielding, and it often sits at the top of that range. The original PSU-1 is non-negotiable. Without it, the preamp is essentially useless.
Buyers should watch for two known issues: relay wear in the stepped attenuator and aging signal-path capacitors. Over decades, the gold relays can oxidize or stick, causing channel imbalance or dropouts at certain volume steps. A full relay service, either cleaning or replacement, is often necessary. The original coupling capacitors are high-grade, but they degrade over time and should be recapped by a qualified technician for optimal performance. A No.26 that hasn't been maintained may measure poorly and sound veiled or harsh. Properly restored, it still competes with modern preamps costing twice as much.
Market Value
┌──────────────────────────────────────────────────────────────────────────┐ │ MARK LEVINSON NO.26 Aug 2026 │ ├──────────────────────────────────────────────────────────────────────────┤ │ High $5,120 Latest $115 │ │ Median $53 Trend ▼ Down │ │ Low $11 Volume ~6/mo │ ├──────────────────────────────────────────────────────────────────────────┤ │ $6,000 ┤ │ │ │ │ │ │. │ │ $3,429 ┤ │ │ │ │ │ │ │ │ │ │ │ $0 ┤ . . .. . . .. . .│ │ ├─────────────────────────────────────────────────────────────────│ │ vol │▂ ▂ ▆ ▂█ ▂ ▂ ▂▄ ▂ ▂│ │ └─────────────────────────────────────────────────────────────────│ │ 2026-05 2026-06 2026-08│ └──────────────────────────────────────────────────────────────────────────┘
eBay completed sales. Excludes accessories, parts, and non-working units. Hover points for details.
