Garrard 5 Turntable

Name: Garrard 5
Brand: Garrard

The Garrard 5 is a historically significant three-speed manual turntable produced between 1950 and 1953. As one of the first consumer turntables released by Garrard after World War II, it marked the brand’s return to the domestic audio market. Though overshadowed by later classics like the 301 and 401, the Model 5 laid the groundwork for Garrard’s reputation in precision engineering and high-fidelity playback.

Designed as a single-play, manual operation turntable, the Model 5 was built for reliability and simplicity, using an idler wheel drive system to achieve stable speeds across all three standard formats of the era: 78, 45, and 33.3 RPM.

Specifications

Feature	Specification
Model	Garrard 5
Production Years	1950–1953
Drive System	Idler wheel
Speeds	33.3, 45, and 78 RPM
Motor	Hysteresis synchronous (AC)
Platter	Die-cast aluminum with rubber mat
Tonearm	Pivoted, straight tube (user-installed)
Cartridge Compatibility	Varies (dependent on user installation)
Power Requirements	Mains-powered (no internal amplification)
Dimensions	Approx. 14" x 16" x 5" (with arm)
Weight	~12 lbs (5.4 kg)
Color Options	Black or ivory lacquer finish

> Note: Impedance, sensitivity, and power specifications are not applicable (N/A) as the turntable produces a phono-level signal dependent entirely on the cartridge and preamp used.

Historical Significance

The Garrard 5 emerged during a pivotal time in audio history—the early 1950s, when the record industry was transitioning from shellac 78s to vinyl LPs and 45s. As one of Garrard’s first post-war consumer turntables, the Model 5 helped re-establish the British brand in homes across Europe and North America.

While not as refined or high-performance as the legendary Garrard 301 (introduced in 1953), the Model 5 shared key design philosophies: robust construction, precise speed control via idler drive, and modularity for integration into console systems or standalone use. It served as a direct predecessor to the 301 and influenced the development of Garrard’s professional and consumer lines throughout the 1950s and 60s.

Despite its modest features, the Model 5 played a crucial role in positioning Garrard as a leader in turntable engineering—a reputation that would peak with the 301 and 401 models.

Sound Signature

The sonic character of the Garrard 5 is heavily influenced by the choice of cartridge and tonearm, as it was typically sold without either. When paired with appropriate vintage or modern components, it delivers a sound typical of idler-wheel designs:

Solid, well-defined bass due to strong motor coupling and speed stability
Good midrange clarity, especially with moving magnet or moving coil cartridges
Potential for mechanical noise (rumble or idler whine) if not properly maintained

Its idler drive system provides excellent speed consistency, though it can transmit more vibration than belt-drive alternatives. When restored correctly, the Model 5 offers a warm, dynamic analog experience reflective of early high-fidelity design.

Common Issues & Maintenance Tips

Due to its age, most surviving Garrard 5 units require restoration to function reliably. Key areas to inspect and maintain include:

1. Idler Wheel

The rubber idler tire often hardens, cracks, or deforms after decades of disuse.
Solution: Rebuild or replace with a modern recast idler wheel (available from specialty audio restoration suppliers).

2. Motor and Lubrication

The motor contains internal bushings that require light oiling.
Old grease can gum up, causing speed fluctuations or motor strain.
Tip: Use synthetic clock oil on bushings; avoid over-lubrication.

3. Motor Mounts

Rubber motor mounts degrade over time, leading to increased vibration.
Solution: Replace with silicone mounts or dampening pads for improved isolation.

4. Wiring and Grounding

Original cloth-insulated wiring may be brittle or unsafe.
Recommendation: Replace with modern shielded cable and ensure proper grounding to reduce hum.

5. Platter and Bearing

Clean the main spindle and bearing well; use a light oil (e.g., sewing machine oil).
Check for wobble or excessive play in the platter.

6. Speed Calibration

Use a strobe disc and AC-powered light source to verify correct RPM.
Adjust motor pulley position if necessary (some models allow minor speed tuning).

Collectibility & Market Value

The Garrard 5 is considered a niche vintage item with moderate collectibility (rated 4/10). It appeals primarily to:

Vintage audio restorers
Historians of post-war British engineering
Enthusiasts building period-correct systems

Market Value: $50–$150 USD

Lower end: Non-working units needing full restoration
Higher end: Fully serviced, original-finish models with correct arm and platter

While not a high-value collector’s item, the Model 5 holds sentimental and historical value as a foundational piece in Garrard’s legacy.

Final Thoughts

The Garrard 5 may not boast the performance of its famous successors, but it represents a critical chapter in the evolution of high-fidelity audio. As a sturdy, no-frills turntable from the dawn of the LP era, it offers a tangible connection to post-war innovation and the early days of home stereo.

For the vintage audio enthusiast, restoring a Garrard 5 is a rewarding project—one that bridges the gap between mechanical simplicity and the pursuit of analog excellence.
