Altec Lansing 906-8A Compression Driver
The Altec Lansing 906-8A is a high-efficiency compression driver developed during the 1960s and produced through the 1970s. It was known for clarity, sensitivity and a heavy-duty build. It became a staple in professional sound reinforcement, cinema audio, broadcast studios and high-end home audio systems. It was part of Altec's line of studio monitor components, and it helped shape the "West Coast sound" era, which was bright, articulate and dynamic.
Specifications
| Parameter | Specification |
| Model | 906-8A |
| Brand | Altec Lansing |
| Year of Production | 1960s–1970s |
| Power Handling | 50W RMS, 100W peak (per driver) |
| Impedance | 8 ohms |
| Sensitivity | 110 dB (1W/1m) |
| Magnet Type | Alnico |
| Diaphragm Material | 1-inch phenolic |
| Horn Compatibility | Exponential aluminum horns (e.g., 802, 811) |
| Design | High-efficiency compression driver |
| Configuration | Single-channel driver unit |
Historical Significance
The Altec Lansing 906-8A was engineered as a professional-grade driver, built for reliability and sonic precision under demanding conditions. It was commonly paired with Altec's multicellular horns such as the 802 and 811. Together they formed the core of many studio monitor and public address systems. It also went into movie theaters, recording studios and live sound setups, and it became a benchmark in mid-to-high frequency reproduction.
During the 1960s and 1970s, the 906-8A contributed to the sound of West Coast audio engineering - crisp highs, strong midrange articulation and high output efficiency. These drivers were often found in systems used by major studios and sound contractors, where durability and consistent performance were paramount.
Sound Signature
The 906-8A sounds bright, detailed and highly dynamic, with pronounced midrange presence. Its sensitivity of 110 dB lets it produce substantial volume with minimal amplifier power, which suits passive systems and vintage tube amplifiers. The clarity can border on harshness when it is paired with overly resonant horns or used in acoustically reflective rooms. Crossover integration and horn matching are essential to a balanced result.
Thanks to its Alnico magnet and phenolic diaphragm, the driver has smooth harmonic distortion characteristics and excellent transient response. Audiophiles and vintage audio enthusiasts prize both.
Common Issues and Maintenance Tips
Despite the heavy build, the 906-8A is subject to age-related wear. Owners should be aware of the following common issues:
- Magnetic Degradation: Alnico magnets can lose strength over decades, reducing efficiency and output. Remagnetization by a specialist can restore performance.
- Diaphragm Wear: The phenolic diaphragm may develop cracks or tears, especially if exposed to humidity or physical stress. Replacement diaphragms and reconing services are available from vintage audio specialists.
- Terminal Corrosion: Original binding posts are prone to oxidation. Cleaning with contact cleaner or upgrading to modern terminals improves reliability.
- Horn Matching: Optimal performance requires proper pairing with compatible exponential horns. Mismatched horns can lead to uneven dispersion and frequency response anomalies.
Maintenance Recommendations:
- Inspect diaphragm regularly using a magnifying glass for signs of wear.
- Store in a dry, temperature-stable environment to prevent material degradation.
- Use a dedicated crossover with appropriate roll-off slopes (typically 12–18 dB/octave) to protect the driver.
- Consider professional servicing if output diminishes or distortion increases.
Collectibility and Market Value
The Altec 906-8A holds a collectibility rating of 7/10 among vintage audio enthusiasts. Its historical importance, high efficiency and professional use keep demand steady in the used market. Well-maintained units with strong magnets and intact diaphragms command premium prices.
As of current market trends, individual drivers typically sell for $150 - $300, depending on condition, originality and included accessories (such as original mounting hardware or documentation). Sets of matched drivers, or drivers sold with compatible horns, often fetch higher values, especially in audiophile and restoration circles.
Conclusion
The Altec Lansing 906-8A remains a hallmark of mid-20th-century audio engineering excellence. Its combination of high sensitivity, durable construction, and vivid sonic character continues to attract professionals, restorers, and high-fidelity enthusiasts. With proper care and system integration, the 906-8A delivers a listening experience that few modern drivers can replicate—offering a direct link to the golden age of analog sound.
