Accuphase C-202 (1987)

Name: Accuphase C-202
Brand: Accuphase

Stereo preamplifier introduced in January 1987 with fully balanced circuitry and a high-performance phono stage.

Overview

The Accuphase C-202 is a stereo preamplifier manufactured by Accuphase Laboratory, Inc., originally known as Kensonic Laboratory, Inc. Introduced in January 1987, it features a full complement of functions including a high-performance phono equalizer amplifier and a dedicated CD buffer circuit. Designed as the smaller model in Accuphase's lineup, it is not one of the brand’s best-known or most expensive pieces.

Specifications

Production Start	January 1987
Original Price	￥215,000
Frequency Response (High Level)	20 Hz to 20,000 Hz ±0.2 dB
Total Harmonic Distortion (High Level)	0.005%
Signal-to-Noise Ratio (High Level)	110 dB
Input Sensitivity (High Level)	150 mV
Rated Output Voltage (Balanced)	4.0 V
Rated Output Voltage (Unbalanced)	2.0 V
Maximum Output Voltage	5.0 V
Power Consumption	18 watts
Dimensions	445 mm W × 111 mm H × 340 mm D
Weight	9.0 kg
Power Supply	100 VAC / 117 V / 220 V / 240 V, 50Hz/60Hz
Semiconductors	Transistors: 110; FETs: 54; ICs: 12; Diodes: 79

Design

The C-202 uses fully balanced circuitry from input to output, with JFETs at every stage and no ICs or capacitors in the signal path. The CD signal path includes only a -20dB attenuator and volume control, and the dedicated CD buffer uses a class A push-pull balanced circuit in all stages. The balanced input amplifier for CD employs a differential push-pull circuit, and the input buffer uses a cascode connection driven by a cascode push-pull stage. Input switching and tape monitoring are handled by sealed audio-grade relays with a crossbar twin contact system. The power supply features a large-capacity toroidal transformer, dedicated rectifiers for left and right channels, four 10,000 μF filter capacitors, and a multiple power supply system with constant voltage regulators for each amplifier block. Natural Persimmon sideboards are fitted on both sides.

Market

Current market value for the C-202 is between $2000 and $3000 AUD. Mechanical switches under the front panel flap may require servicing over time. The service manual is essential, as the unit requires adjustment of eight DC offset points per channel for the two balanced amplifier stages.
